Dettagli
| Caratteristica | LH19 3.0 | LH25 3.0 | LH35 3.0 |
| Image Sensor | VOx Uncooled Focal Plane Arrays | VOx Uncooled Focal Plane Arrays | VOx Uncooled Focal Plane Arrays |
| Max. Resolution | 384×288 | 384×288 | 384×288 |
| Frame Rate | 50Hz | 50Hz | 50Hz |
| Pixel Interval | 12μm | 12μm | 12μm |
| Response Waveband | 8μm to 14μm | 8μm to 14μm | 8μm to 14μm |
| NETD |
Less than 15 mK (@25°C),F#=1.0
|
Less than 15 mK (@25°C),F#=1.0
|
Less than 15 mK (@25°C),F#=1.0
|
| Lens (Focal Length) | 19mm, f1.0 | 25mm, f1.0 | 35mm, f1.0 |
| Focus Mode | Focus Ring | Focus Ring | Focus Ring |
| Detection Range | 900m | 1200m | 1800M |
| Min. Focusing Distance | 3m | 3m | 3.5m |
| Magnification | 1.9x - 15.2x (8x) | 2.5x - 20x (8x) | 3.4x - 27.2x (8x) |
| Field of View (H × V) |
13.8°X8.8°/20.5m x15.4m
|
10.5°X6.84°/28.4m x11.2m
|
7.5°X4.6°/13.1m x8.0m
|
| Display | 1920x1080, 0.49 inch, AMOLED |
1920x1080, 0.49 inch, AMOLED
|
1920x1080, 0.49 inch, AMOLED
|
| Palettes | Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome |
Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome
|
Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome
|
| Exit Pupil | 6mm | 6mm | 6mm |
| Eye Relief | 20mm | 20mm | 20mm |
| Diopter (Range) | -5D to +3D | -5D to +3D | -5D to +3D |
| Brightness Adjustment | Yes | Yes | Yes |
| Tone Adjustment | Cold, Warm | Cold, Warm | Cold, Warm |
| Contrast Adjustment | Yes | Yes | |
| Zoom Pro | Yes | Yes | Yes |
| HSIS (Shutterless Image System) | Yes | Yes | Yes |
| Image Pro 3.0 | Yes | Yes | Yes |
| Record Video | Yes | Yes | Yes |
| Capture Snapshot | Yes | Yes | Yes |
| Audio Recording | Yes | Yes | Yes |
| Standby Mode | Yes | Yes | Yes |
| Built-in Memory | Built-in EMMC (64 GB) | Built-in EMMC (64 GB) | |
| PIP | Yes | Yes | Yes |
| Hotspot | 2.4 GHz/5 GHz Wi-Fi Waveband |
2.4 GHz/5 GHz Wi-Fi Waveband
|
Yes
|
| Hot Track | Yes | Yes | Yes |
| Distance Measurement | Yes | Yes | Yes |
| Local Album | Yes | Yes | Yes |
| Battery Type | Replaceable and Rechargeable Li-ion 18650 Battery |
Replaceable and Rechargeable Li-ion 18650 Battery
|
Replaceable and Rechargeable Li-ion 18650 Battery
|
| Battery Operating Time | 5-hour continuous running with hotspot on (@25°C) 4.5-hour continuous running with hotspot on (@-20°C) |
5-hour continuous running with hotspot on (@25°C) 4.5-hour continuous running with hotspot on (@-20°C)
|
5-hour continuous running with hotspot on (@25°C) 4.5-hour continuous running with hotspot on (@-20°C)
|
| Type-C Power Supply | 5V DC, 2A Supports External Power Supply, Support Direct Charging |
5V DC, 2A Supports External Power Supply, Support Direct Charging
|
5V DC, 2A Supports External Power Supply, Support Direct Charging
|
| Protection Level | IP67 | IP67 | IP67 |
| Dimension | 158.4x53.6 x 49.5mm | 158.4x53.6 x 49.5mm |
169.6x53.6 x 49.5mm
|
| Weight | 331 g with battery | 328.5 g with battery | 328.5 g with battery |
| Working Temperature | From -30°C to 45°C (-22°F to 113°F); Humidity: 90% or Less |
From -30°C to 45°C (-22°F to 113°F); Humidity: 90% or Less
|
From -30°C to 45°C (-22°F to 113°F); Humidity: 90% or Less
|
Maggiori informazioni
| Marca | HIKMICRO |
|---|
